10KW 48V Split Phase Solar Inverter AC input 120V/240V AC output 120V/240V

Name: 10KW 48V Split Phase Solar Inverter AC input 120V/240V AC output 120V/240V
Brand: SunGoldPower
SKU: SPH10048P
Price: 1580.00 USD
Availability: InStock

Brand SunGoldPower In Stock

$1,580.00 In Stock

No sales tax collected at checkout where applicable.

Estimated delivery Calculating current delivery window…

Secure checkoutProtected payment Free shippingView shipping policy Eligible returnsView return policy Authorized dealerSunGoldPower warranty

Need help choosing? Not sure if this is the right setup for you? Chat with our team, call support or check your expected loads before ordering. Call 1-844-747-6767 Open Power Planner

SunGoldPower Solar Inverter

10KW 48V Split Phase Solar Inverter AC input 120V/240V AC output 120V/240V

The 10KW 48V Split Phase Solar Inverter AC input 120V/240V AC output 120V/240V is designed for split-phase backup and off-grid systems that need stable power conversion for larger loads. It helps turn stored battery energy into usable household power while keeping the system practical for residential and remote installations.

10KW48V120V240VSplit PhaseIn StockSKU SPH10048P

Clean power conversion

Helps turn stored battery energy into usable AC power for everyday loads, backup circuits, and off-grid applications.

Built for battery systems

A practical match for solar storage builds where the inverter needs to work smoothly with a dedicated battery bank.

Split-phase capability

Supports larger home and system layouts that need 120V and 240V power from the same inverter platform.

Built to anchor your power system

A strong inverter is the part of the system that customers notice when the power actually has to work. This model is built for dependable conversion in solar and storage projects where the system needs to support more than basic charging.

Use it as the core conversion point for a battery-backed power system.
Supports split-phase system layouts for larger 120V/240V loads.
A practical fit for backup power, off-grid power, workshops, mobile builds, and residential energy projects.
Helps keep system design cleaner when you need dependable AC output from stored energy.

Package Includes

1x 10KW 48V Split Phase Solar Inverter AC input 120V/240V AC output 120V/240V

Includes the selected item based on the current package option.

10KW 48V Split Phase Solar Inverter AC input 120V/240V AC output 120V/240V
Model SKU	SPH10048P
MODEL
Product Type	Inverter
ELECTRICAL
Rated Output Power	10,000 W
Peak Output Power	20,000 W
Battery Voltage	48 V DC
AC Output Voltage	120 V single phase or 120/240 V split phase
Maximum Combined Charging Current	200 A
Solar Charge Controllers	Two integrated MPPT controllers
Maximum PV Open-Circuit Voltage	500 V DC per input
Parallel Capability	Up to 6 units; supports 120 V single phase, 120/240 V split phase, or 208 V three-phase configurations
Charge Voltage Setting Range	48-58.4 V in 0.4 V steps
Rated Output Voltage	120/240 VAC (single-phase/split-phase)
Rated Frequency	50/60 Hz
Output Wave	Pure sine wave
Parallel Number	6
Battery Type	Lithium-ion battery/lead-acid battery/user-defined battery
Rated Battery Voltage	48 Vdc
Voltage Range	40 Vdc−60 Vdc
Max. PV Charge Current	200 A
No. of MPPT Trackers	2
Max. Input Power	11,000 W
Max. Input Current	22/22 A
Input Voltage Range	90 VAC−140 VAC
Input Frequency Range	50/60 Hz
Bypass Overload Current	63 A
MPPT Tracking Efficiency	99.9%
Maximum Battery-Mode Efficiency	92%
Max Peak Power	20000W
Output Configuration	Split phase
CONNECTIONS
Communications	CAN, RS485, and included Wi-Fi monitoring
BMS Communication	CAN
PHYSICAL
Dimension	620 mm445 mm130 mm
Weight	27 kg
OPERATING LIMITS
Certification	UL 1741 certified by ETL for off-grid solar systems
Ambient temperature	-10°C−55°C (14°F−131°F), to ensure optimal operation
Protection level	IP20, for indoor use only
