Renogy 200W 12V Monocrystalline Solar Premium Kit w/ 20A MPPT Charge Controller
$329.99
In Stock
No sales tax collected at checkout where applicable.
Estimated delivery
Calculating current delivery window…
Secure checkoutProtected payment
Free shippingView shipping policy
Eligible returnsView return policy
Authorized dealerRenogy warranty
Need help choosing?
Not sure if this is the right setup for you?
Chat with our team, call support or check your expected loads before ordering.
Call 1-844-747-6767
Open Power Planner
This kit comes with two 100W Polycrystalline Solar Panels totaling 200 Watt, one 20 Amp MPPT Charge Controller, 20ft MC4 Extension Cables, and two sets of Z brackets for Mounting.
Package Includes
1x Renogy 200W 12V Monocrystalline Solar Premium Kit w/ 20A MPPT Charge Controller
Includes the selected item based on the current package option.
| RNG-100D-SS 100W Monocrystalline Solar Panel | |
| Model SKU | RNG-KIT-PREMIUM200D-RVR20-G3-US |
|---|---|
| Electrical Data | |
| Maximum Power at STC | 100W |
| Open-Circuit Voltage (Voc) | 24.3V |
| Short-Circuit Current (Isc) | 5.21A |
| Optimum Operating Voltage (Vmp) | 20.4V |
| Optimum Operating Current (Imp) | 4.91A |
| Module Efficiency | 17.8% |
| Maximum System Voltage | 600VDC |
| Maximum Series Fuse Rating | 15A |
| Mechanical Data | |
| Solar Cell Type | Monocrystalline (6.5 x 3.3 in) |
| Number of Cells | 36 (3 x 12) |
| Dimensions | 41.8 x 20.9 x 1.4 in / 1,062 x 530 x 35mm |
| Weight | 14.1 lbs / 6.4kg |
| Front Glass | Tempered Glass 0.13 in / 3.2mm |
| Frame | Anodized Aluminium Alloy |
| Connectors | Solar Connectors |
| Fire Rating | Class C |
| Thermal Characteristics | |
| Operating Module Temperature | -40°F to 176°F |
| Nominal Operating Cell Temperature (NOCT) | 47 ± 2°C |
| Temperature Coefficient of Pmax | -0.37% / °C |
| Temperature Coefficient of Voc | -0.28% / °C |
| Temperature Coefficient of Isc | 0.05% / °C |
| Solar Connectors | |
| Rated Current | 30A |
| Maximum Voltage | 1,000VDC |
| Maximum AWG Size Range | 10 AWG |
| Temperature Range | -40°F to 194°F |
| IP Rating | IP67 |
| Junction Box | |
| IP Rating | IP65 |
| Diode Type | HY 10SQ050 |
| Number of Diodes | 2 |
| Output Cables | 14 AWG, 1.96ft |
| Certifications | |
| CE, ISO 9001 | Yes |
| RENOGY ROVER 20 AMP MPPT SOLAR CHARGE CONTROLLER | |
| Electrical Parameters | |
| Nominal System Voltage | 12/24V (Auto-Detect for Non-Lithium Batteries) |
|---|---|
| Rated Charge Current | 20A |
| Max. PV Input Voltage | 95 VDC |
| Max. PV Input Power | 12V / 260W, 24V / 520W |
| Power Consumption | ＜100mA/12V; ＜58mA/24V |
| Max Battery Voltage | 32V |
| Ground Type | Negative |
| Electrical Protection | Overcharging, over-discharging, overload, and short circuit.Capable of charging over-discharged lithium batteries. |
| Environmental Data | |
| Protection Level | IP32 |
| Operating Temperature Range | -35°C to 45°C; -31°F to 113°F |
| Storage Temperature Range | -35°C to 75°C; -31°F to 167°F |
| Operating / Storage Humidity | ≤ 90%, No Condensation |
| Temperature Compensation | -3mV/°C/2V |
| Mechanical Specifications | |
| Dimensions | 210 x 151 x 68 mm; 8.27 x 5.95 x 2.69 in |
| Weight | 3.1 lbs / 1.4 kg |
| Max. Terminals Size | 8 AWG 10mm2 |
| Certifications | |
| CE | YES |
| FCC Class B Part 15 Compliant | YES |
| Warranty | |
| Material and workmanship warranty | 2 Year |
