Renogy
Renogy ANL Fuse Set w/ Fuse - 20A
$12.99
In Stock
No sales tax collected at checkout where applicable.
Estimated delivery
Calculating current delivery window…
Secure checkoutProtected payment
Free shippingView shipping policy
Eligible returnsView return policy
Authorized dealerRenogy warranty
Need help choosing?
Not sure if this is the right setup for you?
Chat with our team, call support or check your expected loads before ordering.
Call 1-844-747-6767
Open Power Planner
ANL Fuse Set with Fuse — 100A
Protect a compatible solar power system from overcurrent with a Renogy ANL Fuse Set. Designed to help safeguard a charge controller, battery, inverter and connecting wires, the fuse uses alloy and brass-copper materials with a clear, non-conductive protective cover for suitable custom installations.
Package Includes
1x Renogy ANL Fuse Set w/ Fuse - 20A
Includes the selected item based on the current package option.
| RAD40ANL-RR08 | |
| Model SKU | RNG-SET-ANL20-G1-US |
|---|---|
| Cable Specifications | |
| Cable Size | 8 AWG |
| Testing Standard | UL1015 |
| Rated Voltage | 600VDC |
| Operating Temperature | <105℃ |
| Terminal Type | 5/16 in Ring Lug |
| Cable Length | 0.65 ft / 198 mm |
| Fuse Specifications | |
| Fuse Type | ANL Fuse |
| Rated Voltage | 32VDC |
| Rated Current | 40A |
| Operating Temperature | -40℃ to 125℃ |
| Mechanical Specifications | |
| Fuse Dimensions | 124 x 37.6 x 37.5 mm / 4.88 x 1.48 x 1.48 in |
| Warranty | |
| Warranty | 1-Year Material and Workmanship Warranty |
Specification Sheet
Technical specifications, dimensions, electrical ratings, and certifications.
View PDF
User Manual
Installation instructions, setup guidance, operation, and troubleshooting.
View PDF
Warranty Sheet
Warranty coverage, product protection details, and manufacturer terms.
View PDF
No documentation files have been added for this product yet.
