Renogy MRBF Terminal Fuse - 30A

Brand Renogy In Stock

$12.99 In Stock

No sales tax collected at checkout where applicable.

Bundle Option Choose your bundle

Quantity

Estimated delivery Calculating current delivery window…

Secure checkoutProtected payment Free shippingView shipping policy Eligible returnsView return policy Authorized dealerRenogy warranty

Need help choosing? Not sure if this is the right setup for you? Chat with our team, call support or check your expected loads before ordering. Call 1-844-747-6767 Open Power Planner

MRBF Terminal Fuse - 100A

Protect compatible off-grid electrical circuits with a compact terminal fuse designed for suitable combiner-box or fuse-holder installations across a range of amperage requirements.

Renogy MRBF Terminal Fuse

Compact circuit protection designed for suitable electrical systems from waterways to roadways.

Integrated Circuit Protection

The MRBF fuse supports a streamlined installation by integrating circuit protection in a compact terminal-mounted format.

Renogy MRBF fuse and combiner-box protection diagram

Centralized Electrical Safeguarding

Attach the MRBF fuse directly to a compatible positive terminal copper plate to help protect the connected circuit without an external inline fuse connection.

Renogy MRBF fuse mounted to terminal connection

What is the purpose of the screw fitting?

The included screw is designed to assist with installing the MRBF fuse on a compatible Renogy combiner box.

Package Includes

1x Renogy MRBF Terminal Fuse - 30A

Includes the selected item based on the current package option.

MRBF Terminal Fuse
Model SKU	RPD30TF-BL-G1-US
Specifications
Current Rating	30A
Voltage Rating	58V
Interrupt Rating	10,000A @ 14VDC; 5,000A @ 32VDC; 2,000A @ 58VDC
Dimensions	23.5 x 20 x 11.5mm / 0.93 x 0.79 x 0.45 in
Mounting Hole Size	5/16" / M8
Insulating Body Material	Ceramic
Cover Material	PES
Certifications
RoHS, UL, CE	Yes
Warranty
Material and Workmanship Warranty	1 Year
