Renogy Waterproof Solar Connector In-Line Fuse Holder w/ Fuse - 10A Renogy Waterproof Solar Connector In-Line Fuse Holder w/ Fuse
SKU: RNG-CNCT-FUSE10-G1-US
$16.99
In Stock
No sales tax collected at checkout where applicable.
Estimated delivery
Calculating current delivery window…
Secure checkoutProtected payment
Free shippingView shipping policy
Eligible returnsView return policy
Authorized dealerRenogy warranty
Need help choosing?
Find the right setup for you.
Talk it through with our team, or size your system with the Power Planner.
Call 1-844-747-6767
Open Power Planner
Solar Connector Waterproof In-Line Fuse Holder w/ Fuse — 10 Amp
Add single-circuit protection to a compatible solar array with a waterproof in-line fuse holder fitted with solar connector leads on both ends. The selected 10 Amp fuse option is designed to help prevent excessive current from damaging connected solar panels.
Package Includes
1x Renogy Waterproof Solar Connector In-Line Fuse Holder w/ Fuse - 10A
Includes the selected item based on the current package option.
| 10A Solar Connector Waterproof In-Line Fuse Holder w/ Fuse | |
| Selected variant SKU | RNG-CNCT-FUSE10-G1-US |
|---|---|
| Rated Current | 10A |
| Degree of Protection | IP2* / IP67 |
| Rated Voltage | 1000 V DC |
| Flame Class | UL94-V0 |
| Test Voltage | 6000V (50Hz, 1 min) |
| Safety Class | II |
| Overvoltage Category | CATIII |
| Suitable Connector | Solar Connector |
| Contact Resistance of Plug Connector | 1mΩ |
| Insertion Force / Withdrawal Force | ≤50N / ≥50N |
| Contact Material | Copper, Silver Plated |
| Replaceable | Yes |
| Insulation Material | PPO |
| Temperature Range | -40°C to +125°C |
Product reference specifications
Specifications for the selected option are shown above. These product reference details describe the listing and its available configurations.
| 10A Solar Connector Waterproof In-Line Fuse Holder w/ Fuse | |
| Electrical Parameters | |
| Rated Current | 10A |
|---|---|
| Rated Voltage | 1000 V DC |
| Test Voltage | 6000V 50Hz, 1 min |
| Overvoltage Category | CATIII |
| Contact Resistance of Plug Connector | 1mΩ |
| Contact Material | Copper, Silver Plated |
| Insulation Material | PPO |
| Protection & Safety | |
| Degree of Protection | IP2* / IP67 |
| Flame Class | UL94-V0 |
| Safety Class | II |
| Suitable Connector | Solar Connector |
| Insertion Force / Withdrawal Force | ≤50N / ≥50N |
| Fuse | Replaceable |
| Temperature Range | -40°C to +125°C |
| 15A Solar Connector Waterproof In-Line Fuse Holder w/ Fuse | |
| Electrical Parameters | |
| Rated Current | 15A |
| Rated Voltage | 1000 V DC |
| Test Voltage | 6000V 50Hz, 1 min |
| Overvoltage Category | CATIII |
| Contact Resistance of Plug Connector | 1mΩ |
| Contact Material | Copper, Silver Plated |
| Insulation Material | PPO |
| Protection & Safety | |
| Degree of Protection | IP2* / IP67 |
| Flame Class | UL94-V0 |
| Safety Class | II |
| Suitable Connector | Solar Connector |
| Insertion Force / Withdrawal Force | ≤50N / ≥50N |
| Fuse | Replaceable |
| Temperature Range | -40°C to +125°C |
| 20A Solar Connector Waterproof In-Line Fuse Holder w/ Fuse | |
| Electrical Parameters | |
| Rated Current | 20A |
| Rated Voltage | 1000 V DC |
| Test Voltage | 6000V 50Hz, 1 min |
| Overvoltage Category | CATIII |
| Contact Resistance of Plug Connector | 1mΩ |
| Contact Material | Copper, Silver Plated |
| Insulation Material | PPO |
| Protection & Safety | |
| Degree of Protection | IP2* / IP67 |
| Flame Class | UL94-V0 |
| Safety Class | II |
| Suitable Connector | Solar Connector |
| Insertion Force / Withdrawal Force | ≤50N / ≥50N |
| Fuse | Replaceable |
| Temperature Range | -40°C to +125°C |
| 30A Solar Connector Waterproof In-Line Fuse Holder w/ Fuse | |
| Electrical Parameters | |
| Rated Current | 30A |
| Rated Voltage | 1000 V DC |
| Test Voltage | 6000V 50Hz, 1 min |
| Overvoltage Category | CATIII |
| Contact Resistance of Plug Connector | 1mΩ |
| Contact Material | Copper, Silver Plated |
| Insulation Material | PPO |
| Protection & Safety | |
| Degree of Protection | IP2* / IP67 |
| Flame Class | UL94-V0 |
| Safety Class | II |
| Suitable Connector | Solar Connector |
| Insertion Force / Withdrawal Force | ≤50N / ≥50N |
| Fuse | Replaceable |
| Temperature Range | -40°C to +125°C |
| Warranty Information | |
| Accessories Warranty | 1-Year Material Warranty |
Frequently Asked Questions
Clear answers to common questions about this product, setup, compatibility, and use.
Where does the Renogy inline solar fuse holder connect in a PV string?
It uses a solar connector lead at each end so it can be placed in a compatible PV conductor path. Confirm polarity, series-fuse requirements, conductor size, array voltage, and controller limits before adding it to the string.
Which fuse rating should I select for the waterproof solar connector holder?
The listing offers multiple current choices. Use the module's maximum series-fuse rating, string current, conductor ampacity, connector limits, and applicable code; do not choose from panel wattage alone.
When does this inline PV fuse assembly achieve its published IP67 protection?
Its weather protection depends on properly mated connectors, an intact holder, and correct assembly. An open end, damaged seal, loose cap, or poorly supported cable can compromise the installation even though the product is sold for outdoor PV use.
Does an inline fuse replace the array disconnect or charge-controller protection?
No. It provides single-circuit overcurrent protection; disconnecting, combining, grounding, surge protection, and battery-side protection are separate functions determined by the system architecture and applicable rules.
Can the solar fuse holder be opened while the array is producing current?
Isolate the PV source using the approved shutdown sequence before opening the holder or separating connectors. Solar wiring can remain energized in daylight, and interrupting loaded DC current can arc or damage the contacts.
