SKU: SGN-590-BDG1x2
Each SGN-590-BDG1 module is rated at 590W under STC. Select the pack quantity you need—2 through 20 panels in even increments—and check the selected variant before checkout. The 590W rating is per panel; actual array output depends on sunlight, temperature, wiring, shading, and rear-side exposure.
Each panel lists 52.35V open-circuit voltage (Voc), 44.40V maximum-power voltage (Vmp), 13.90A short-circuit current (Isc), and 13.29A maximum-power current (Imp) at STC. Check cold-weather string voltage and parallel-string current against the selected inverter or controller.
The rear of the dual-glass module can capture reflected light when mounting height, surface reflectivity, spacing, and shading allow it. Treat 590W front-side STC power as the nameplate; do not assume a fixed rear-side gain for every site.
Each panel measures 89.69 × 44.65 × 1.38 in and weighs 69.45 lb. SunGoldPower lists a 12-year materials/workmanship warranty and a 30-year linear power warranty. Plan lifting, structure, mounting, and service access for the full selected pack.
What's included: the number of SGN-590-BDG1 panels shown in your selected pack option. For example, a 2-panel pack contains two 590W modules; a 4-panel pack contains four. Mounting hardware, inverter, and controller are not part of the stated panel pack unless separately listed in the selected offer.
Our solar panel selection guide explains panel selection for different setups. The bifacial panel guide compares the relevant panel format; check this product’s electrical ratings before pairing it with other equipment.
Compare wattage per panel, physical dimensions, Voc, current and connector type before planning an array.
See the 590 Watt Bifacial N-Type Monocrystalline Solar Panel (31 PANELS) for another SunGoldPower solar panel option.
| 590 Watt Bifacial N-Type Monocrystalline Solar Panel SGN-590-BDG1 UL61730 CEC Listed | |
| Selected variant SKU | SGN-590-BDG1x2 |
|---|---|
| MODEL | |
| Model / SKU | SGN-590-BDG1 (pack-size suffix varies by selected variant) |
| Product Type | Solar Panel |
| Available Variants | Pack of 2; Pack of 4; Pack of 6; Pack of 8; Pack of 10; Pack of 12; Pack of 14; Pack of 16; Pack of 18; Pack of 20 |
| ELECTRICAL | |
| Maximum Power Voltage (Vmp, STC) | 44.40 V |
| Maximum Power Current (Imp, STC) | 13.29 A |
| Rated Power (STC / NMOT) | 590 W / 452 W |
| Open-Circuit Voltage (STC / NMOT) | 52.35 V / 50.12 V |
| Short-Circuit Current (STC / NMOT) | 13.90 A / 11.20 A |
| Module Efficiency | 22.8% |
| Bifacial Peak Power at 13.5% Rear Irradiance | 654 W |
| Bifacial Short-Circuit Current | 15.40 A |
| Power Tolerance | 0 to +5 W |
| Maximum System Voltage | 1500 V |
| Maximum Rated Fuse Current | 30 A |
| Cell Type | N-type monocrystalline (M10) |
| Number of Cells | 144 |
| Output Wire | 4 mm² IEC / 12 AWG UL |
| Output Cables | 12 AWG (1ft per cable) |
| Listed Solar Power | 590W |
| Cell Technology | N-type Monocrystalline |
| Module Design | Bifacial |
| CONNECTIONS | |
| Connector | MC4 compatible |
| PHYSICAL | |
| Dimensions | 89.69 × 44.65 × 1.38 in (2278 × 1134 × 35 mm) |
| Weight | 69.45 lb (31.5 kg) |
| Frame | Anodized aluminum alloy |
| Wire Length | 47.24 in (1200 mm), including connector |
| Product Dimension | 89.69 x 44.65 x 1.38 inch |
| Two-Panel Package Weight | 140 lb (manufacturer-listed 2-panel package) |
| OPERATING LIMITS | |
| Operating Temperature Range | -40°F to 185°F (-40°C to 85°C) |
| Maximum Permissible Module Temperature | 185°F (85°C) |
| Nominal Module Operating Temperature | 109.4°F ±3.6°F (43°C ±2°C) |
| Certifications | UL61730 Certified by ETL ，ISO 9001， ISO 14001， ISO 45001 |
| Warranty | 12 years material and workmanship warranty,30 years Linear power warranty |
| Listed Certifications | UL 61730, CEC listed |
