BRAVO 30 — 30 Amp MPPT Solar Charge Controller
The BRAVO 30 is an MPPT solar charge controller with up to 99.5% tracking efficiency and 98% conversion efficiency. It auto-detects 12V/24V systems, supports 8 + 1 battery types, and includes an LCD + LED display with built-in Bluetooth for app monitoring via the Rich Solar App.
Advanced MPPT Technology
Up to 99.5% tracking efficiency and 98% conversion efficiency, with stable operation under low-light or partial shading conditions.
Flexible Battery Compatibility
Auto-detects 12V/24V systems and supports 8 + 1 battery types, including GEL, AGM, WET, Crystal, Calcium, LiFePO4, LTO, LCO, and Custom, with a multi-stage charging algorithm and customizable parameters.
Intelligent Monitoring
LCD + LED display for real-time solar input, battery status, and customizable parameters, plus built-in Bluetooth for app monitoring via the Rich Solar App.
Product Overview
The BRAVO 30 is a 30A MPPT solar charge controller using an advanced MPPT algorithm rated up to 99.5% tracking efficiency and 98% conversion efficiency, with stable operation under low-light or partial shading conditions. Maximum solar input current and maximum charging current are both 30A, with a recommended solar power of 500W at 12V or 1000W at 24V. The solar input voltage range is 8V–100V, with an MPPT voltage range of 15V–72V.
The controller auto-detects 12V/24V systems and supports 8 + 1 battery types: GEL, AGM, WET, Crystal, Calcium, LiFePO4, LTO, LCO, and Custom. A multi-stage charging algorithm with customizable parameters is included. Protection covers over-voltage, reverse polarity, short-circuit, and over-temperature conditions. The build is rated IP43 for the PCBA and IP22 for the connectors, and is certified to ETL, FCC, CE, and RoHS.
Monitoring is handled through an LCD + LED display showing real-time solar input, battery status, and customizable parameters, alongside built-in Bluetooth for app monitoring through the Rich Solar App. An optional remote meter and temperature sensor are available for enhanced control. Net weight is 1.8 lb, with dimensions of 7.0 × 5.5 × 2.9 in.
Advanced MPPT Technology
- Up to 99.5% Tracking Efficiency.
- 98% Conversion Efficiency.
- Stable Operation Under Low-Light or Partial Shading Conditions.
Flexible Battery Compatibility
- Auto-Detects 12V/24V Systems.
- 8 + 1 Battery Types: GEL, AGM, WET, Crystal, Calcium, LiFePO4, LTO, LCO, Custom.
- Multi-Stage Charging Algorithm: Customizable parameters to help extend battery lifespan.
Advanced Protection System
- Multiple Safety Protections: Over-voltage, reverse polarity, short-circuit, over-temperature.
- Weather-Resistant Build: IP43-rated PCBA and IP22 connectors.
- Certified to ETL, FCC, CE, RoHS.
Intelligent Monitoring System
- LCD + LED Display: Real-time solar input, battery status, customizable parameters.
- Built-In Bluetooth: App monitoring via the Rich Solar App.
- Optional Remote Meter and Temperature Sensor.
Full Specifications
| SKU | RS-MPPT30PB |
| Maximum Solar Input Current | 30A |
| Maximum Charging Current | 30A |
| Recommended Solar Power | 500W (12V) / 1000W (24V) |
| Nominal System Voltage | 12V/24V Auto-Detect |
| Solar Input Voltage Range | 8V–100V |
| MPPT Voltage Range | 15V–72V |
| Maximum Conversion Efficiency | 98% |
| Maximum MPPT Tracking Efficiency | 99.5% |
| Battery Compatibility | GEL, AGM, WET, Crystal, Calcium, LiFePO4, LTO, LCO, Custom |
| Connectivity | Built-In Bluetooth (Optional Remote Meter & Temperature Sensor) |
| Protection Rating | IP43 PCBA, IP22 Connection |
| Net Weight | 1.8 lb |
| Dimensions (L×W×H) | 7.0 × 5.5 × 2.9 in |
| Certifications | ETL, FCC, CE, RoHS |
Best Uses
- RVs, trailers, campers, vans, and boats
- Off-grid 12V or 24V systems
- Setups using LiFePO4, LTO, or other lithium battery chemistries
- Installations wanting app-based monitoring via Bluetooth
Key Benefits
- 30A MPPT with up to 99.5% tracking and 98% conversion efficiency
- 8V–100V solar input range
- 9 battery type presets including Custom
- Built-in Bluetooth with LCD + LED display
- ETL, FCC, CE, RoHS certified
| Specifications | |
| Model SKU | RS-MPPT30P |
|---|---|
| Maximum Solar Input Current | 30A |
| Maximum Charging Current | 30A |
| Recommended Solar Power | 500W (12V) / 1000W (24V) |
| Nominal System Voltage | 12V/24V Auto-Detect |
| Solar Input Voltage Range | 8V-100V |
| MPPT Voltage Range | 15V-72V |
| Maximum Conversion Efficiency | 98% |
| Maximum MPPT Tracking Efficiency | 99.5% |
| Battery Compatibility | GEL, AGM, WET. CRYSTAL, CALCIUM, LiFePO., LTO, LCO, Custom |
| Connectivity | Built-in Bluetooth (Optional Remote Meter & Temperature Sensor) |
| Protection Rating | IP43 PCBA, IP22 Connection |
| Net Weight | 1.8 lb |
| Dimensions (LxWxH) | 7.0 x 5.5 x 2.9 in |
