Jackery HomePower 2000 Plus v2 + SolarSaga 500 X Jackery HomePower 2000 Plus v2 + SolarSaga 500 X
SKU: 60-200050-US00481
- Station capacity 2,048Wh
- AC output 2,400W total rated
- Panel set 1 × SolarSaga 500 X (500W nameplate)
This Jackery solar bundle includes one HomePower 2000 Plus v2 power station and one SolarSaga 500 X panel. The panel has a 500W nameplate rating under standard test conditions; the station stores 2,048Wh and provides 2,400W total rated AC output. These are separate solar, storage and output ratings.
What’s in the box
- 1 × HomePower 2000 Plus v2 power station
- 1 × SolarSaga 500 X solar panel
- 1 × AC charging cable
Power station and panel details
The LiFePO4 station has four 120V AC outlets, a 12V DC port, USB-A, and 30W and 140W USB-C outputs. Jackery rates total AC output at 2,400W, with a 4,800W surge peak. The SolarSaga 500 X is a foldable panel rated at 500W ±5% under standard test conditions; it weighs about 22.05 lb and folds to approximately 39.21 × 20.71 × 3.82 inches. Solar charge time varies with sunlight, panel angle and temperature.
Choosing this configuration
This SKU includes one 500 X panel and no expansion battery. For extra stored energy, choose a separately sold, verified compatible Battery Pack 2000 Plus v2. Compare the station-only option and the two-panel bundle.
Manufacturer manuals and connection guides
At a glance
- Battery chemistry: LiFePO4
- Expansion: Battery Pack 2000 Plus v2 sold separately
Plan the 500W solar setup
The included SolarSaga 500 X has a 500W nameplate rating; actual charging depends on sunlight and the station's input limits. Our solar generator charging-time guide explains those variables, and the solar-panel count guide helps compare panel configurations. See the Jackery collection for other packages.
| Specifications | |
| Selected variant SKU | 60-200050-US00481 |
|---|---|
| Power Station Capacity | 2048Wh / 40Ah, 51.2V DC |
| Power Station Cell Chemistry | LiFePO4 |
| Power Station Cycle Life | 6000 cycles to 70%+ capacity |
| Power Station Weight | About 41.45 lb / 18.8 kg |
| Power Station Dimensions | 14.4 × 10.0 × 10.7 in / 36.6 × 25.5 × 27.2 cm |
| Charge Temperature | -10°C to 45°C / 14°F to 113°F |
| Discharge Temperature | -10°C to 45°C / 14°F to 113°F |
| Power Station Warranty | 3+2 Years |
| AC Output | 4 × AC outlets, 120V, 60Hz, 20A Max, 2400W Rated |
| AC Total Output | 2400W Total / 4800W Surge Peak |
| DC Output | 12V DC port, 12V, 10A Max |
| USB-C 30W Output | 30W Max, 5V 3A / 9V 3A / 12V 2.5A / 15V 2A / 20V 1.5A |
| USB-C 140W Output | 140W Max, 5V 3A / 9V 3A / 12V 3A / 15V 3A / 20V 5A / 28V 5A |
| USB-A Output | 18W Max, 5–6V 3A / 6–9V 2A / 9–12V 1.5A |
| DC Expansion Port | 36.8V to 57.6V, 55A Max |
| Charge Mode AC Input | 100V to 120V, 60Hz, 15A Max |
| Bypass Mode AC Input / Output | 100V to 120V, 60Hz, 15A Max |
| DC Input | 16V to 60V, 12A Max / double to 21A, 800W Max |
| Low Voltage DC Input | 11V to 16V, 8A Max / double to 8A Max |
| Bundle contents | 1 × HomePower 2000 Plus v2; 1 × SolarSaga 500 X; 1 × AC charging cable |
| Panel model | SolarSaga 500 X (JS-500A) |
| Panel quantity | 1 |
| Panel peak power | 500W ±5% under standard test conditions |
| Panel open-circuit voltage | 48.5V ±5% |
| Panel short-circuit current | 13.02A ±5% |
| Panel operating voltage at peak power | 41.7V ±5% |
| Panel operating current at peak power | 12.0A ±5% |
| Panel weight | About 22.05 lb ±2.20 lb / 10.5 kg ±0.5 kg |
| Panel folded dimensions | About 39.21 × 20.71 × 3.82 in |
| Panel unfolded dimensions | About 98.15 × 39.21 × 11.57 in |
| Panel waterproof rating | IP68 |
| Power station | 1 × HomePower 2000 Plus v2 |
|---|---|
| Solar panel | 1 × SolarSaga 500 X |
| AC charging cable | 1 |
