The MEGA 200 MAX RS-M200D is a rigid 200W monocrystalline panel for compatible 24V-class solar systems. Its higher operating voltage distinguishes it from the similarly named 12V MEGA 200 panel.

Check controller voltage before matching panels

Use the exact RS-M200D ratings when planning a string or replacing an existing module. Cold-weather open-circuit voltage, array current and the controller’s input limits all matter. A nominal 24V panel designation is not a direct battery connection.

Measure the roof or mounting structure

The documented module is 58.7 × 26.8 × 1.2 inches and weighs 23.6 lb. Allow mounting clearance and cable routing space beyond the panel footprint.

Keep model revisions separate

This page covers RS-M200D using its model-specific September 2024 datasheet. The newer RS-M200P is a different SKU; do not use its images or specifications to identify this panel.

MEGA 200 MAX RS-M200D panel with factory-attached leads
Package Includes
1 × MEGA 200 MAX RS-M200D panel with factory-attached leads
Model RS-M200D
Rated Power (STC) 200W
Maximum Power Voltage (Vmp) 36.3V
Maximum Power Current (Imp) 5.51A
Open Circuit Voltage (Voc) 43.5V
Short Circuit Current (Isc) 5.93A
Maximum System Voltage 1000VDC
Maximum Series Fuse Rating 15A
Module Efficiency 19.7%
Power Tolerance 0 to +5W
Cell Type Monocrystalline
Cell Count 64
Dimensions 58.7 × 26.8 × 1.2 in
Weight 23.6 lb
Factory Leads 12 AWG, 35.4 in each
Junction Box IP67
Operating Temperature -40°C to 85°C
Output Warranty 25-year limited output warranty
Specification Revision Manufacturer RS-M200D datasheet, September 2024
Selected variant SKU RS-M200D
📄
Specification Sheet
Technical specifications, dimensions, electrical ratings, and certifications.
View PDF

Frequently Asked Questions

Clear answers to common questions about this product, setup, compatibility, and use.

Is this the newer MEGA 200 PRO? No. This listing identifies the RS-M200D MEGA 200 MAX. Verify the model label when matching an existing array. Can I connect this directly to a battery? Use a compatible charge controller for a battery-charging system. Match its PV input limits and charging settings to the complete array and battery. What voltage matters when connecting panels in series? The module Voc is 43.5V at standard test conditions. Add the string voltages and account for cold-weather voltage rise before comparing the result with the controller limit. Are mounts and a charge controller included? This is a panel listing with factory-attached leads. Installation-specific mounting, controller, battery and protection are separate.
